Methods of Implementation (MOIs)

The InfiniBand® Trade Association (IBTA) conducts compliance and interoperability tests on all InfiniBand® devices, RoCE devices and cables two times a year. Software Forge has developed detailed methods of implementation of these tests for the IBTA. This page briefly describes the purpose of each of these MOIs and provides a link to the actual document at the IBTA.

Public MOIs are available to both IBTA and non-IBTA members.

Public MOIs

Active Time Domain (ATD) MOI

This MOI describes how to verify Active Cable compliance under stressed conditions. It describes how to properly do the ATD calibration and conduct the testing as performed at the IBTA plugfest events. You can download a presentation on the ATD testing here.

Device (HCA/Switch) Receiver MOI

The MOI describes how to perform Receiver (Rx) tests on an InfiniBand® FDR device.

Device (HCA/Switch) Transmitter MOI

This MOI describes how to perform Transmitter (Tx) tests on an InfiniBand® FDR device.

Vector Network Analyzer (VNA) MOIs

The VNA MOIs explain how to use Keysight 4-Port or 32-Port network analyzers to make the measurements required for the InfiniBand® Architecture Specification Volume 2 for FDR, EDR or HDR cables and connectors.



CIWG Members only MOIs

The following MOIs are only accessible to IBTA members. You may join the CIWG if you would like to become a member. Membership to the CIWG is free to all IBTA members.



InfiniBand® (IB) Interoperability MOI

This MOI explains the setup for InfiniBand® Interoperability testing as used at IBTA Plugfests. It also explains how to run the IB interoperability tests.







Mellanox Eye Opening MOI

Describes how to determine which lane of the cable under test has the minimum eye opening.



Memory Map Validation MOI

Describes the standard CXP and QSFP memory map validation procedures.



RoCE Interoperability MOI

This MOI describes the RDMA over Converged Ethernet (RoCE) interoperability fabric setup and the testing procedures.
